Auveco No. 1043 Metric Fastener Assortment W/O Bin, Quantity - 1 ASST

by Auveco
$586.50
SKU 1043

Ships within 24 hours (M-F)

Product Information

Quantity: 1
Description: Metric Fastener (Regular & Fine Pitch) Assortment
Includes: 1995 Pieces, Planogram And Reorder Labels, Without The 72B-9 Bin
Made In: Mexico

Metric Fastener (Regular & Fine Pitch) Assortment.

Over 1,995 metric cap screws, hex nuts, lock washers and flat washers.

The reorder labels contain the fastener part number, size, description and bar code.

Diameters: M5-.8, M6-1.0, M8-1.25, M8-1.0, M10-1.5, M10-1.25, M10-1.0 & M12-1.75.

Lengths: 10mm through 75mm.

All fasteners are zinc plated except fine pitch cap screws which have a black finish.

All parts are certified to meet or exceed the proper S.A.E. specifications both physically and chemically.


Cap Screw
14583 5mm-.8 x 12mm (DIN 933)
14403 5mm-.8 x 16mm (DIN 933)
14404 5mm-.8 x 20mm (DIN 933)
14405 5mm-.8 x 25mm (DIN 933)
14406 5mm-.8 x 30mm (DIN 933)
15512 5mm-.8 x 40mm (DIN 933)
14584 6mm-1.0 x 10mm (DIN 933)
14407 6mm-1.0 x 12mm (DIN 933)
14408 6mm-1.0 x 16mm (DIN 933)
14409 6mm-1.0 x 20mm (DIN 933)
14410 6mm-1.0 x 25mm (DIN 933)
14411 6mm-1.0 x 30mm (DIN 931)
14412 6mm-1.0 x 35mm (DIN 931)
14413 6mm-1.0 x 40mm (DIN 931)
14585 6mm-1.0 x 50mm (DIN 931)
14588 8mm-1.25 x 12mm (DIN 933)
14419 8mm-1.25 x 16mm (DIN 933)
14420 8mm-1.25 x 20mm (DIN 933)
14421 8mm-1.25 x 25mm (DIN 933)
14422 8mm-1.25 x 30mm (DIN 933)
14423 8mm-1.25 x 35mm (DIN 931)
14424 8mm-1.25 x 40mm (DIN 931)
14425 8mm-1.25 x 45mm (DIN 931)
14426 8mm-1.25 x 50mm (DIN 931)
14428 8mm-1.25 x 60mm (DIN 931)
14429 8mm-1.25 x 70mm (DIN 933)
14589 8mm-1.25 x 75mm (DIN 931)
14430 10mm-1.5 x 20mm (DIN 933)
14431 10mm-1.5 x 25mm (DIN 933)
14432 10mm-1.5 x 30mm (DIN 933)
14433 10mm-1.5 x 35mm (DIN 933)
14434 10mm-1.5 x 40mm (DIN 931)
14435 10mm-1.5 x 45mm (DIN 931)
14436 10mm-1.5 x 50mm (DIN 931)
14438 10mm-1.5 x 60mm (DIN 931)
14439 10mm-1.5 x 70mm (DIN 931)
14440 12mm-1.75 x 25mm (DIN 933)
14441 12mm-1.75 x 30mm (DIN 933)
14442 12mm-1.75 x 35mm (DIN 933)
14443 12mm-1.75 x 40mm (DIN 933)
14445 12mm-1.75 x 50mm (DIN 931)
14446 12mm-1.75 x 60mm (DIN 931)
14447 12mm-1.75 x 70mm (DIN 931)
Hex Nut
14449 5mm-.8 (DIN 934)
14450 6mm-1.0 (DIN 934)
14452 8mm-1.25 (DIN 934)
14454 10mm-1.5 (DIN 934)
14455 12mm-1.75 (DIN 934)
Flat Washer
10578 5mm (DIN 125)
10579 6mm (DIN 125)
10581 8mm (DIN 125)
10582 10mm (DIN 125)
10583 12mm (DIN 125)
Lock Washer
10585 5mm (DIN 127)
10586 6mm (DIN 127)
10588 8mm (DIN 127)
10589 10mm (DIN 127)
10590 12mm (DIN 127)
Fine Cap Screw
11257 8mm-1.0 x 25mm (DIN 961)
14604 8mm-1.0 x 50mm (DIN 960)
14605 10mm-1.25 x 20mm (DIN 961)
11265 10mm-1.25 x 25mm (DIN 961)
11266 10mm-1.25 x 30mm (DIN 961)
11267 10mm-1.25 x 35mm (DIN 961)
11268 10mm-1.25 x 40mm (DIN 961)
11269 10mm-1.25 x 50mm (DIN 961)
14606 10mm-1.25 x 60mm (DIN 961)
11262 10mm-1.0 x 30mm (DIN 961)
11264 10mm-1.0 x 50mm (DIN 961)
Fine Pitch Hex Nut
14453 8mm-1.0 (DIN 934)
14457 10mm-1.25 (DIN 934)
14456 10mm-1.0 (DIN 934)
